GaAs pHEMT MMIC DRIVER AMPLIFIER 3GHz-10GHz

General Description

SAC3906 is a wideband GaAs MMIC driver amplifier which operates between 3GHz~10GHz. The amplifier provides 18dB of gain and 13dBm OutputP-1dB power from a +5V supply voltage.

The chip offers full passivation for increased reliability and moisture protection. This amplifier is the perfect alternative to higher cost hybrid amplifiers.

Feature

  • Frequency : 3GHz～10GHz
  • Gain: 18dB
  • Output P-1dB: 13dBm
  • Supply Voltage: +5V
  • Die Size: 1.74mm×1.22mm×0.1mm

Typical Applications Point-to-Point Radios
SATCOM
Military and Space
Test and Measurement
Radar

Product Data Complete Data Sheet

ABSOLUTE MAXIMUM RATINGS

  • Maximum Input Power +18dBm
  • Channel Temperature +150℃
  • Maximum VD +9V
  • Operating Temperature -55℃～+85℃
  • Storage Temperature -65℃～+150℃
